FireLeaves Electric Bicycle Brushless Motor Kit Review
If you are looking to convert your regular bicycle into an electric one, the FireLeaves Electric Bicycle Brushless Motor Kit is a great option to consider. This rear conversion installation kit is suitable for bikes with a wheel diameter of within 27 inches. Let’s take a closer look at its specifications and features.
Specifications
- Color: Silver, Black
- Material: Aluminum, Copper, Rare Earth Magnet Steel
- Speed Gears: Three(80%, 100%, 110%)
- Motor Efficiency: ≥78%
- Rated Voltage: 24V DC
- Power: 250W
- Temperature Resistance: 120℃/248℉
- Model: MY1016Z3
- Suspension Type: Rear
- Special Feature: Electric
- Torque: About 7.82N·m
- Unload Current: ≤2.2A
- Unloaded Speed: 3850Rpm
- Rated Current: 13A
- Rated Speed(Before Speed Reduction): 3000RPM
- Rated Speed(After Speed Reduction): 330RPM
- Gear Ratio: 9.78:1
- Insulation Class: F
- Protect Grade: IP33
- Motor Controller Voltage: 24/36VDC
- Motor Controller Max Current: 16A
- Motor Controller Power: 250W
- Motor Controller Voltage: 1.1-4.2V
- Under Voltage: 20V
- Brake: Low Level
- Suitable Bike Type: Spoke Wheel Bike
- Suitable Bike Wheel Diameter: ＜68.58cm/27inch
- Suitable Bicycle Hub Diameter: ＜35mm/1.3inch
- Assembly Required: Yes
- Chainwheel Outer Diameter: 134mm/5.27inch
- Chainwheel Inner Diameter: 35mm/1.38inch
- Chainwheel Teeth Space: 12.7mm/0.5inch
- Packaging Size: 26*15*18cm/10.23*5.9*7inch
- Gross Weight: 4.5kg/9.92lbs
Brushless Motor
The FireLeaves Electric Bicycle Brushless Motor Kit features a brushless motor, which offers several advantages. The brushless motor has low friction, low noise, and smooth operation. This results in a comfortable and enjoyable riding experience. Additionally, the brushless motor requires minimal maintenance, and you only need to perform occasional dust removal to keep it in top condition.
IP33 Protection
One of the standout features of this electric bicycle conversion kit is its IP33 protection level. This protection level ensures that the motor is waterproof and dustproof. It effectively extends the service life of the motor by preventing water and dust from causing any damage. You can confidently ride your electric bike in various weather conditions without worrying about motor damage.
Adjustable Speed
The FireLeaves Electric Bicycle Brushless Motor Kit allows you to adjust the speed according to your preference and specific situation during traveling. With three speed gears (80%, 100%, and 110% of the motor speed), you can easily customize your riding experience. Whether you want to conserve battery power or need an extra boost, the adjustable speed feature offers flexibility for any riding scenario.
Reversing Function
Included with the kit is a reversing connector and a reversing switch, providing the convenience of reversing on your electric bike. This feature is especially useful when maneuvering in tight spaces or reversing out of a parking spot. The FireLeaves Electric Bicycle Brushless Motor Kit offers a seamless reversing experience, enhancing the overall usability of your electric bike.
In conclusion, the FireLeaves Electric Bicycle Brushless Motor Kit offers a reliable and efficient solution for converting your regular bicycle into an electric one. With its brushless motor, IP33 protection, adjustable speed, and reversing function, it provides a smooth, customizable, and convenient riding experience. Upgrade your bike with this conversion kit and enjoy the benefits of an electric bicycle.
